Application:
This product is suitable for electric-railway of complex operation conditions.
Advantage:
It can effectively prevent flash accidents and decrease the times of clear and maintenance.
Feature:
It has small volume and when in the tunnel is clear products of porcelain, glass insulator can not instead of it.
| Product Model | Rated Voltage | Rated mechanical Bending Load(KN) |
Lightning Impulse Withstand Voltage(peak) (kv) |
P.F.withstand Voltage (virtual value)(kv) | Min Creepage Distance(mm) | Structure Height H.(mm) |
| FQX1-25 | 25 | 60 | 270 | 130 | 1400 | 650 |
| FQX2-25 | 25 | 60 | 270 | 130 | 1400 | 840 |
| FQX3-25 | 25 | 60 | 270 | 130 | 1400 | 930 |
| FQX4-25 | 25 | 60 | 270 | 130 | 1400 | 645 |
| FQE1-25 | 25 | 60 | 270 | 130 | 1400 | 760 |
| FQE2-25 | 25 | 60 | 270 | 130 | 1400 | 806 |
| FQE3-25 | 25 | 60 | 270 | 130 | 1400 | 836 |
| FQE4-25 | 25 | 60 | 270 | 130 | 1100 | 695 |
